OptiClimate Pro 3 15000 (Three Phase)

The Opticlimate PRO 3 Series is a unique solution to arrange perfection. Through the cooling and heating function, it is possible 365 days per year to achieve a stable climate in which you are never dependent on the outdoor climate.

• Runs on a single phase residential mains supply
• Can be used inside or outside the grow room
• Low noise levels, very quiet when operating
• Auto-shutdown feature protects against leakages and potential hazard
• Water cooling system to deal with high temperatures
• Ceramic heaters to deal with low temperatures
• Circulates air in the grow room
• Water consumption of 1-2 litres per minute
• Pre-heat and slow cool-down function to gradually ease plants into day and night cycles
• Dehumidifies to reduce moisture levels

OptiClimate water-cooled air conditioner is a new solution for the indoor climate control. OptiClimate can be used for circulation, cooling, heating, dehumidifying and filtering. There is more than five years of development and testing in OptiClimate. This has resulted in a fully developed and optimized product that allows to regulate the climate in to perfection, with the lowest possible power consumption.

OptiClimate cools the air using water as a cooling medium and heats through ceramic heating elements. OptiClimate has a water inlet and outlet. The input is connected to the water supply. The drainage is connected to the sewer with a possible branch to a water or nutrient Tank. The cold water is used to cool the air with the result that it is heated to 40-50 ° C. This warm water is discharged into the sewers or can be used for other purposes, such as heating in your room.

The included remote is also a controller which allows all the processes to run fully automatically and be monitored at the same time. Once the minimum temperature (night) and maximum temperature (day) have been set using the remote, the OptiClimate will either heat or cool, depending on the night or day setting, ensuring the preset temperatures will not be exceeded. The night or day setting is controlled by a light sensor. On the day setting (cooling), the Opticlimate also dehumidifies. If required, using the included humidistat, the Opticlimate can also dehumidify when it is on the night setting, thus lowering the humidity.

During daytime operation (cooling) OptiClimate dehumidify the air. Should it be desired OptiClimate can also dehumidify the night conditions so that the humidity is optimal.

Through the use of oversized heat exchangers and the water as a cooling medium, a very high efficiency and hence low current consumption is achieved.

On a 22MM copper pipe, in total 45 to 60KW of cooling power can be connected. On a 16MM copper pipe, it is possible to connect up to 25KW cooling capacity.

Because the Opticlimate is placed in a (semi) closed system, it is very easy to add CO2 without much waste, to the cultivation area, wherein the air is continuously recirculated. Since there will only be a limited export of air, no major CO2 equipment is needed and models up to 4KW are more then sufficient.

The Opticlimate system works even better when combined with Dimlux lighting and a CO2 addition. By means of corresponding software it’s possible to adjust the behavior of CO2 and various control equipment to work together with the Opticlimate, to provide the perfect indoor climate.

One OptiClimate Pro 3 can manage two rooms by having them on a split cycle so one on the night phase and one on the day phase and by adding in a 3 way valve and an extra temperature sensor.

Opticlimate Pro 3 3500
Ideal for 6 x 600w HPS grow lights or 4 x 1000w HPS grow lights
Dimensions: 100cm x 50cm x 42cm
Weight: 57kg (125 lb)

Opticlimate Pro 3 6000
Ideal for 10 x 600w HPS grow lights or 6 x 1000w HPS grow lights
Dimensions: 115cm x 53cm x 43cm
Weight: 73kg (160 lb)

Opticlimate Pro 3 10000
Ideal for 16 x 600w HPS grow lights or 10 x 1000w HPS grow lights
Dimensions: 115cm x 56cm x 50cm
Weight: 92kg (202.8 lb)

Opticlimate Pro 3 15000 Three Phase
Ideal for 24 x 600w HPS grow lights or 15 x 1000w HPS grow lights
Dimensions: 121cm x 70cm x 54cm
Weight: 123kg (271.2 lb)

Opticlimate Pro 3 15000 Inverter (Runs on both single phase and three phase supplies)
Ideal for 24 x 600w HPS grow lights or 15 x 1000w HPS grow lights
Dimensions: 121cm x 70cm x 54cm
Weight: 123kg (271.2 lb)
